Kromschroder VAG 240R/NWAE, air/gas ratio control (88000383)
SKU:
88000383
Kromschroder
88000383
Kromschroder air/gas ratio control with solenoid valve
For safeguarding and control of the gas pressure, Class A pressure regulator to EN 88, Class A solenoid valve to EN 161, for gas, air and biologically produced methane, pu max. 500 mbar (7 psig), with pilot lamp, IP 65
Size 2
EU certified
Inlet: DN 40 (1 1/2'')
Outlet: DN 40 (1 1/2'')
Rp internal thread
Quick opening, quick closing
Mains voltage: 230 V AC, 50/60 Hz
Electrical connection: plug with socket
Valve seat: normal
Connection kit for air control pressure psa: 1 compression fitting, 2 pressure test points pd and psa
Accessories, right: 2 screw plugs
Accessories, left: 2 screw plugs
For safeguarding and control of the gas pressure, Class A pressure regulator to EN 88, Class A solenoid valve to EN 161, for gas, air and biologically produced methane, pu max. 500 mbar (7 psig), with pilot lamp, IP 65
Size 2
EU certified
Inlet: DN 40 (1 1/2'')
Outlet: DN 40 (1 1/2'')
Rp internal thread
Quick opening, quick closing
Mains voltage: 230 V AC, 50/60 Hz
Electrical connection: plug with socket
Valve seat: normal
Connection kit for air control pressure psa: 1 compression fitting, 2 pressure test points pd and psa
Accessories, right: 2 screw plugs
Accessories, left: 2 screw plugs
Replacing a VAG 240R/NWAE, 88000383 air/gas ratio control is a good solution to make your equipment work again. We offer a wide range of Kromschroder spare parts for burners, gas trains etc. We supply original Elster (Kromschröder) products.
If you have any queries about Kromschroder valvario gas valves or any other Kromschroder spare parts, please write us at 624burner@gmail.com, quoting the item code 88000383.
- Inlet size DN 40 (1 1/2")
- Inlet type Rp internal thread
- Outlet size DN 40 (1 1/2")
- Outlet type Rp internal thread
- Pu max. 0.5 bar
- Opening Quick
- Closing Quick
- Voltage 230 V AC
- Weight, kg 4,673
- Commodity code 84818059
- Country of origin DE
