Honeywell VE4015B1111T solenoid valve DN15 360mb 230V IP65 PG11 throttle

Honeywell model VE4015B1111T gas solenoid valve, which defaults to a closed position, engineered for gas flow control. The VE4015B1111T gas valve from Honeywell ensures safe shut-off and precise regulation of gas supply in various combustion systems, including blower burners, atmospheric boilers, melting and incineration furnaces, as well as other industrial applications.

Honeywell VE4015B1111T gas valve features:

Honeywell VE4015B 1111T gas valve is a normally closed valve featuring a spring-loaded valve disc that remains closed when not energized. It includes an adjustable flow regulator located on top of the coil. The valve opens and closes within 1 second, and it operates at a maximum frequency of 20 cycles per minute. Honeywell VE4015 B 1111T combined gas valve housing designed with wrench bosses on both the inlet and outlet sides, making pipe installation straightforward. Additionally, there are two auxiliary pressure taps with Rp 1/4” threaded connections on the inlet pressure side. The coil is field-replaceable, suitable for continuous energization, and can rotate 360°. An internal fine mesh screen is also included.

Honeywell VE4015B 1111T combined gas valve technical data:

• Pipe sizes: Inlet and outlet 3/8” up to 2” internal parallel pipe thread according to ISO 7-1
• Mounting and orientation: The valve may be assembled on the pipeline within plus or minus 90 degrees of the vertical axis and 30 cm. air space around the coil assy
• Torsion and bending stress: Pipe connections meet group 2, according to EN161 requirements
• Ambient temperature range: -15 ... 60 °C
• Electrical connection: Plug connection according to PG11
• Optional: Male DIN plug connector according to ISO4400
• Coil insulation solenoid valves: Insulation material according to class F
• Valve body: Aluminum alloy die-cast
• Bottom plug: Rp 1/4” for Closed Position Indication (CPI) switch
• Strainer: AISI 303 steel
• Closing spring: AISI 302 steel
• Valve plunger: Chrome plated Fe 360B steel sliding on anti-friction bearing
• Seals and gaskets: Hydrocarbon resistant NBR rubber type
• Optional: Viton rubber type

Honeywell VE4015 B 1111T CVI valve standards and approvals:

Honeywell VE4015B 1111T gas valve in accordance with EN161 standards. Honeywell VE4015B1111T compact gas unit conform to the following EC directives:

• Gas Appliance Directive (90/396/EEC) PIN: CE-0063AP3075/1
• Low Voltage Directive (73/23/EEC)
• Electro Magnetic Compatibility Directive (89/336/EEC)

Replacing a Honeywell VE 4015 B 1111T solenoid valve DN15 is a good solution to make your equipment work again. We offer a wide range of Honeywell spare parts for burners, gas trains etc. We supply original Elster (Kromschröder) & Honeywell (Maxon) products.

If you have any queries about Honeywell shut-off gas valves or any other Honeywell spare parts, please write us at 624burner@gmail.com, quoting the item code VE4015B1111T.
