Honeywell S7800A2142/U 4-line display; EN, FR, SP

Honeywell S7800A2142 keyboard display module provides comprehensive information on the current status and operational sequence of the burner. Honeywell S7800 A 2142 display module data on time intervals, synchronization, lockouts, as well as user-defined and service priority messages. Honeywell S7800A 2142 keyboard display module is compatible with various relay modules, including RM7800, RM7840, RM7838, RM7895, RM7890, RM7885, and RM7823, offering versatile and convenient control for a range of systems.

Honeywell S7800A2142 display module technical data:

• Ambient temperature: -40 C to +60 C (-40 F to +140 F)
• Power supply: 13 V peak two-half-period rectification (+20/-15%)
• Dimensions: width - 123 mm; height - 73 mm; thickness - 23 mm
• Weight: 113g

Honeywell S7800 A 2142 display module accessories:

• 204718B NEMA1 Cover assembly
• 204718C NEMA4 cover assembly with reset (reset) button
• 205321B Bracket for concealed (recessed) mounting
• 221818A Extension cable kit for remote installation of a display module with a keyboard
• S7810A1009 CONTROLBUS data bus module
• 203765 Mounting bracket for remote displays
• 203968A Remote display power supply (removable)
• 204718A NEMA4 Cover assembly

Replacing a Honeywell S 7800 A 2142/U 4-line display; EN is a good solution to make your equipment work again. We offer a wide range of Honeywell spare parts for burners, gas trains etc. We supply original Elster (Kromschröder) & Honeywell (Maxon) products.

If you have any queries about Honeywell control devices or any other Honeywell spare parts, please write us at 624burner@gmail.com, quoting the item code S7800A2142/U.
